BetaFPV Moxon Radio Transmitter Antenna V2 (1pcs)

The BetaFPV Moxon Radio Transmitter Antenna V2 is an essential upgrade for any FPV enthusiast looking to enhance their drone's communication capabilities. This antenna features a compact and lightweight design, making it ideal for both racing and freestyle flying. The Moxon V2 antenna offers improved range and signal quality, ensuring a stable connection between your drone and the transmitter.

Designed for easy installation, this antenna is compatible with a variety of transmitters and provides excellent performance in diverse environments. With its durable construction, the Moxon antenna can withstand the rigors of FPV flying while maintaining reliable signal transmission. Upgrade your FPV setup with the BetaFPV Moxon Radio Transmitter Antenna V2 and experience the difference in performance.

Key Features:

• Enhanced Signal Quality: Offers improved range and stability for reliable communication.
• Compact Design: Lightweight and easy to install, perfect for racing and freestyle.
• Durable Construction: Built to withstand the challenges of FPV flying.

A ton of ExpressLRS items are available now!

Specification

Moxon Antenna

• Coaxial cable length: 49mm(2.4G)/72mm(915M/868M)
• Connector: SMA Male

• Gain: 5.6dBi(2.4G)/5.7dBi(915M)/5.7dBi(868M)
• VSWR: <2.0(2.4G)/<2.0(915M)/<2.0(868M)
• Suggested for: BETAFPV Nano TX Module/BETAFPV Micro TX Module, Any 2.4G/868MHz/915MHz TX module or radios

Moxon Antenna V2

• Coaxial cable length: 65mm(2.4G)/90mm(915M)
• Connector: SMA Male
• Gain: 5.4dBi(2.4G)/5.9dBi(915M)
• VSWR: <2.0(2.4G)/<2.0(915M)
• Polarization type: Linear polarization
• Suggested for: Any 2.4G/915MHz TX module or radios
• Suggested for: BETAFPV Nano TX Module/BETAFPV Micro TX Module, Any 2.4G/868MHz/915MHz TX module or radios

New Features on Moxon Antenna V2

BETAFPV Moxon Antenna has been very popular with pilots since its release. By taking the features of Moxon and adding some new ones, the coaxial cable of Moxon V2 is soldered to the antenna, decreasing the signal transmission loss for better performance. Besides, the soldered joint is protected by an injection molding cover, making it a whole unit and very easy to install.

Which antenna should I choose? Can it replace the stock radio antenna on the Frsky Taranis series or TBS Tango series?

Pilots would upgrade their radios that already support swappable antennas with this Moxon antenna. Note that do NOT use the antenna with the wrong frequency. Even if they look almost the same outside, they will have totally different performances at the wrong frequency point.

The BETAFPV Moxon antenna is directional to the front. Below is the antenna 3D radiation pattern image.

Package

• 2 * BETAFPV Moxon Antenna or 1 * BETAFPV Moxon Antenna V2
