Expected shipping date is August 17th for this item.

Attention: This radio is Mode 2. left stick throttle

The term "game changer" gets tossed around frequently in this industry. We believe DJI has done just that in developing these goggles and the ultra-low latency 720p 120fps HD FPV system behind them. You'll see the details and features below, and they are definitely impressive but the step up in performance and visual immersion this technology provides is something you have to experience for yourself to fully appreciate.

This combo includes DJI FPV Goggles a DJI FPV Air Units, and a DJI FPV Remote Controller. Everything you need to convert a quads to incredible HD FPV and DJI RC Link!

These goggles must be used in conjunction with a DJI FPV Air Unit, but do not require the use of a DJI FPV Remote Controller.

The crisp 720p image, unmatched 120Hz refresh rate, and adjustable (up to 54°) field of view provide new levels of immersion and performance in FPV goggles. The FPV feed can be set to 60fps in High Quality Mode to maximize bit rate for an incredibly vivid flight experience, or crank it up to 120fps in Low Latency Mode to prioritize performance for edge-of-your-seat HD racing like you never imagined possible. The DJI FPV System has as much to offer casual mid-range cruisers as it does hardcore racers and freestyle flyers.

8 DJI FPV Systems can fly together at a time for full digital racing sessions, and a spectator function allows a 2nd DJI FPV goggle to connect to your FPV feed for scenic ride alongs, or blowing minds with freestyle tricks. Record all the action to your goggle DVR at 720p 60fps, and don't forget the Air Unit is capable of recording at 1080p 60fps and 720p 120fps glory!

The optional DJI FPV Remote Controller ties the system together perfectly, allowing users to remotely set parameters of the DJI FPV Goggles, the DJI Air Unit, and the DJI FPV Camera. If you want to keep the trusty RC transmitter you know and love, that's totally fine too! Just be sure to pick up at least one DJI FPV Air Unit to go with these goggles and you've got an integrated airborne solution for FPV/HD Camera, HD DVR and VTX! Keep in mind that the DJI FPV System is good for 4KM of range, so you might want to upgrade your existing RC transmitter to a 900Mhz module like FrSky R9 or TBS Crossfire to keep up!

DJI took extra care making these goggles lighter and more comfortable than previous models. The overall fit and function of these goggles is fantastic, with the sleek and practical design touches and attention to detail that DJI renowned for. Thanks to adjustable FoV, IPD, and image scaling, you're sure to find your perfect settings settings.

So get ready to take off into a whole new world of FPV. The hype is real.

Features

Goggles

Minimum End-to-End Latency within 28ms
720p 120 FPS Digital High Definition Display
Focus Mode
Strong Anti-Interference
Maximum of 8 Channels (5.8GHz)
4Km Transmission Range
Live Streaming Broadcast
Audience Function
PID Tuning
720p 60 FPS Onboard Recording
Video Playback
Engineered to be Lighter and More Comfortable

Remote Controller

Ultra Low Latency (>7ms) Between Controller & Air Unit
4KM Control Distance
High Capacity Battery Ensures Longer Use Time
Closed-Loop Software Operation

Air Unit

1080p 60fps / 720p 120fps DVR
Powerful DJI HDL FPV Transmission System
Embedded RC Receiver
Multi Antenna Technology
Durable Aluminum Housing
Maximum 8 Channels

Camera

150° Ultra-Wide-Angle Lens
Three Picture Modes for Different Scenarios (Standard/Racing/LED)
Adjustable Brightness & Saturation

Specifications

Goggles

Screen Size: 2 Inch x 2
Screen Resolution (Single Screen): 1440×810
Screen Refresh Rate: 120 Hz
FOV: Adjustable from 30° to 54°
Image Size: Adjustable from 50% to 100%
Interpupillary Distance: Adjustable from 58 to 70mm
Communication Frequency: 5.725-5.850 GHz
Transmitter Power (EIRP) FCC/MIC: <30 dBm; CE: <14 dBm; SRRC: <19 dBm
Live View Mode: Low Latency Mode: 720p 120fps
Live View Mode: High Quality Mode: 720p 60fps
Video Format: MP4 (H.264)
Supported Video Play Format: MP4, MOV, MKV (Video format: H.264; Audio format: AAC-LC, AAC-HE, AC-3, MP3)
Power Input: 7.4-17.6V
Battery: 6.6 - 21.75V External Battery
Total Power Consumption: 7W
Supported Storage Card: MicroSD Cards with Capacities of up to 128GB
Operating Temperature: 32° to 104° F (0° to 40° C)
Weight: Approx. 415 g (headband and antennas included)
Dimensions: 184×122×110mm (w/ antennas) 202×126×110mm (w/o antennas)

Remote Controller

Operation Frequency 5.725-5.850 GHz
Max. Transmission Distance (Unobstructed, free of interference) FCC/SRRC: 4 KM; CE: 0.7 KM
Transmitter Power (EIRP) FCC: <30 dBm; CE: <14dBm; SRRC:<19dBm
Operation Current/Voltage 0.6A @ 7.6V
Operation Temperature 0° to 40°C (32° to 104°F)
Charging Temperature 5° to 40°C (41° to 104°F)
Weight 765g

Transmitter Battery

Remote Controller Intelligent Battery (WM37-4920mAh-7.6V)
Battery Type LiPo 2S
Capacity 4920mAh
Voltage 7.6V
Energy 37.39Wh

Air Unit

Input Power 7.4-17.6 V, about 4-9 W
Operating Frequency: 5.725-5.850 GHz
Transmitter Power (EIRP) FCC/SRRC: <30 dBm;
CE: <14 dBm
Min. Latency (end-to-end) Low Latency Mode (720p/120fps): <28 ms
High Quality Mode (720p/60fps): <40 ms
Max. Transmission Distance FCC/SRRC: <4 km; CE: <0.7 km
Video Format MP4 (Video format: H.264; Audio format: ACC-LC)
I/O Interface USB-C, MMCX, 3-in-1 port, microSD card slot
Supported Flight Control System F3, F4, F7
Operating Temperature Range 32°to 104°F (0° to 40°C)
Weight: Air Unit (Camera included): 45.8 g
Air Unit Dimensions: 44×37.8×14.4mm
Camera Dimensions: 27.4×21.1×20.1mm
Coaxial Cable Length: 100mm

Channels Info FCC

Channels: 8
Channel 1: 5660
Channel 2: 5695
Channel 3: 5735
Channel 4: 5770
Channel 5: 5805
Channel 6: 5878
Channel 7: 5914
Channel 8: 5839

CE/SRRC

Channel 1: 5735
Channel 2: 5770
Channel 3: 5805
Channel 8: 5839

MIC

Channel 1: 5660
Channel 2: 5700
Channel 8: 5745

Camera

Sensor 1/3.2'' CMOS; Effective Pixels: 4 M
Lens 2.1 mm, f/2.1
Shutter Rolling shutter
ISO 100-25600
FOV 150°(D); 122°(H); 93°(V)
Dimension 22.1×21.1×20.1 mm
Weight 8.2 g

Includes

1x DJI P1GS FPV Goggle
1x Goggle Strap
4x Antennas
1x Power Cable
1x USB Type C Cable
1x Carry Pouch
1x DJI FPV Remote Controller - Mode 2
1x Remote Controller Intelligent Battery
1x Camera
1x Air Unit Module
2x Air Unit Antenna (MMCX Elbow)
1x Coaxial Cable
1x Air Unit 3in1 Cable
